LCD has helped lots of customers in many projects not only as a manufacturer of conventional LED lights for industry, but above all in the segment of the development of special lights too. A very important and challenging field is that of the special lights. The development of High-quality lights fo......
LCD has helped lots of customers in many projects not only as a manufacturer of conventional LED lights for industry, but above all in the segment of the development of special lights too. A very important and challenging field is that of the special lights. The development of High-quality lights for this area worked and sustainability has necessary high quality and service guaranteed.
The LCD-FE® special light series is ideally used in challenging environments such as building lighting, roadway and car parking construction, loading area, etc. Different requirements called for different solutions. The diverse portfolio therefore offers the opportunity to find the right product for these special circumstances.
Features & benefits
| CERTIFICATIONS | CE RoHs SAA C-tick TUV ETL |
| HOUSING | Aluminum alloy ADC12. |
| LENS | 4mm thick front tempered glasses. +95% light transmission. Shock and vibrations resistant. |
| PERFORMANCE | 10400 to 20800 lumens Up to 130-155 lm/w. From 50W up to 200W. L70 (hrs) rated > 60,000 hours. |
| IP65/ IP66 RATED | Dust tight and protected against big waves or strong water jetting Ideal for heavy industry, mining, refineries, chemical industry, coastal marine facilities and corrosive applications. |
| MOUNTING | Surface, wall mount standard (adjustable mount bracket included). |
| OPERATING TEMPERATURE | From -30°F up to 131° (-30°C to 55°C). |
| DIMMING | 1-10V dimming standard or PWM on requests . |

IP / IK protection
| Model No | LCD-FE-50 | LCD-FE-80 | LCD-FE-100 | LCD-FE-150 | LCD-FE-200 |
| LED Source | LUMILEDS SMD3030/5050 | LUMILEDS SMD3030/5050 | LUMILEDS SMD3030/5050 | LUMILEDS SMD3030/5050 | LUMILEDS 3030/5050 |
| CCT | 2700K-6500K | 2700K-6500K | 2700K-6500K | 2700K-6500K | 2700K-6500K |
| Luminous Efficiency | 130lm-155lm/w | 130lm-155lm/w | 130lm-155lm/w | 130lm-155lm/w | 130lm-155lm/w |
| Beam angle | |||||
| Power supply | Meanwell / Ph driver | Meanwell / Ph driver | Meanwell / Ph driver | Meanwell / Ph driver | Meanwell / Ph driver |
| Input Voltage | 90-305V,50/60Hz | 90-305V,50/60Hz | 90-305V,50/60Hz | 90-305V,50/60Hz | 90-305V,50/60Hz |
| PF | >0.95 | >0.97 | >0.97 | >0.97 | >0.97 |
| THD | <20% | <20% | <20% | <20% | <20% |
| IP Rating | IP65 / IP66 | IP65 / IP66 | IP65 / IP66 | IP65 / IP66 | IP65 / IP66 |
| Operating Temperature | -30ºC to +55ºC | -30ºC to +55ºC | -30ºC to +55ºC | -30ºC to +55ºC | -30ºC to +55ºC |
| Certifications | CE,ROHS, SAA,C-tick, TUV | CE,ROHS, SAA,C-tick, TUV | CE,ROHS, SAA,C-tick, TUV | CE,ROHS, SAA,C-tick, TUV | CE,ROHS, SAA,C-tick, TUV |
| Dimension (MM) | 362x290x240mm | 362x290x240mm | 362x290x240mm | 362x290x240mm | 362x290x240mm |
| Watt options | 50W | 80W | 100W | 150W | 200W |
| N.W. (KG) | 10.6KG | 10.6KG | 10.6KG | 10.6KG | 10.6KG |
