SL010 150W High Transmittance LED Street Light with Ce
SL010 50W 60W 100W 120W 150W 180W 200W 240W LED Street LightKey Feature 1.High bright LED, module design LED Street Light, 2.SL010 Series , 50W, 60W, 100W, 120W, 150W,180W,200W,240W 3.Input 85-265VAC for all 4.Light body: Die-casting aluminum housing 5.Mask: high transmittance,high qu......
Send Inquiry
Product Description
SL010 50W 60W 100W 120W 150W 180W 200W 240W LED Street Light
Key Feature
1.High bright LED, module design LED Street Light,
2.SL010 Series , 50W, 60W, 100W, 120W, 150W,180W,200W,240W
3.Input 85-265VAC for all
4.Light body: Die-casting aluminum housing
5.Mask: high transmittance,high quality tempered glass,
6.Driver with CE, silicone perfusion, waterproof heat stronger,
7.Radiator: Integration aluminum + convection design,
8.Power cord: bold industrial grade copper wire,
9.Waterproof: IP67
10.Whole light luminous efficacy ≥85lm/w,
11.lifespan >50,000 hours
12.CCT 2700-6500K
13.Great illuminating angle: 140°*70°
14.Aging test at least 12 hours for all LED light source,driver before shipment.
15.Warranty 3 years
Technical Specifications
Key Feature
1.High bright LED, module design LED Street Light,
2.SL010 Series , 50W, 60W, 100W, 120W, 150W,180W,200W,240W
3.Input 85-265VAC for all
4.Light body: Die-casting aluminum housing
5.Mask: high transmittance,high quality tempered glass,
6.Driver with CE, silicone perfusion, waterproof heat stronger,
7.Radiator: Integration aluminum + convection design,
8.Power cord: bold industrial grade copper wire,
9.Waterproof: IP67
10.Whole light luminous efficacy ≥85lm/w,
11.lifespan >50,000 hours
12.CCT 2700-6500K
13.Great illuminating angle: 140°*70°
14.Aging test at least 12 hours for all LED light source,driver before shipment.
15.Warranty 3 years
Technical Specifications
| Model | SL010-50 | SL010-60 | SL010-100 | SL010-120 | SL010-150 | SL010-180 | SL010-200 | SL010-240 |
| POWER | 50W | 60W | 100W | 120W | 150W | 180W | 200W | 240W |
| DRIVER | Meanwell | Meanwell | Meanwell | Meanwell | Meanwell | Meanwell | Meanwell | Meanwell |
| LED CHIP | Bridgelux | Bridgelux | Bridgelux | Bridgelux | Bridgelux | Bridgelux | Bridgelux | Bridgelux |
| MODULE AMOUNT | 1*50W | 1*60W | 2*50W | 2*60W | 3*50W | 3*60W | 4*50W | 4*60W |
| CASING MATERIAL | AL6063 | AL6063 | AL6063 | AL6063 | AL6063 | AL6063 | AL6063 | AL6063 |
| ANGLE REGULATION | Non-adjustable | Non-adjustable | Non-adjustable | Non-adjustable | Non-adjustable | Non-adjustable | Non-adjustable | Non-adjustable |
| VOLTAGE | 85-265VAC | 85-265VAC | 85-265VAC | 85-265VAC | 85-265VAC | 85-265VAC | 85-265VAC | 85-265VAC |
| FREQUENCY | 50/60 Hz | 50/60 Hz | 50/60 Hz | 50/60 Hz | 50/60 Hz | 50/60 Hz | 50/60 Hz | 50/60 Hz |
| POWER FACTOR | >0.95 | >0.95 | >0.95 | >0.95 | >0.95 | >0.95 | >0.95 | >0.95 |
| LUMINOUS FLUX (lm) | 6000lm | 7200lm | 12000lm | 14400lm | 18000lm | 21600lm | 24000lm | 28800lm |
| CORRELATED COLOR TEMP. (CCT) | 3000K-6000K | 3000K-6000K | 3000K-6000K | 3000K-6000K | 3000K-6000K | 3000K-6000K | 3000K-6000K | 3000K-6000K |
| COLOR RENDERING INDEX (CRI) | 80 | 80 | 80 | 80 | 80 | 80 | 80 | 80 |
| BEAM ANGLE | 140°X70° | 140°X70° | 140°X70° | 140°X70° | 140°X70° | 140°X70° | 140°X70° | 140°X70° |
| PROTECTION GRADE | IP67 | IP67 | IP67 | IP67 | IP67 | IP67 | IP67 | IP67 |
| LIFE SPAN | 50000H | 50000H | 50000H | 50000H | 50000H | 50000H | 50000H | 50000H |
| WARRANTY | 3 years | 3 years | 3 years | 3 years | 3 years | 3 years | 3 years | 3 years |
| AMBIENT HUMIDITY | ≤95% | ≤95% | ≤95% | ≤95% | ≤95% | ≤95% | ≤95% | ≤95% |
| AMBIENT TEMP. | -20°C~50°C | -20°C~50°C | -20°C~50°C | -20°C~50°C | -20°C~50°C | -20°C~50°C | -20°C~50°C | -20°C~50°C |
| PCS/CARTON | 1 | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
| PRODUCT SIZE (mm) | 305*290*85mm | 305*290*85mm | 445*290*85mm | 445*290*85mm | 585*290*85mm | 585*290*85mm | 725*290*85mm | 725*290*85mm |
| PACKING SIZE (mm) | 380*355*120 | 380*355*120 | 510*355*120 | 510*355*120 | 640*355*120 | 640*355*120 | 785*355*125 | 785*355*125 |
| PRODUCT Weight.(kg) | 2.85 | 2.85 | 3.91 | 3.91 | 5.5 | 5.5 | 6.5 | 6.5 |
| G.W.(kg) | 3.5 | 3.5 | 4.5 | 4.5 | 6.1 | 6.1 | 7.1 | 7.1 |
| REMARK | 1.For the LED Street light, still need Pole, PV Panel , PV mounting,Solar Charge Controller, Solar Battery and Battery Box. pls inquire while need. | |||||||
| 2.CCT: Warm white(WW) 2700-6500K;Natural white(NW)4000-4500K;Cold white(CW) 6000-6500K | ||||||||
